Audels answers on automobiles, for owners, operators, repairmen ... including chapters on the storage battery, electric vehicles, motor cycles, overhauling the car, etc. Fully illustrated and indexed (1911)
Booth, Charles Edwin, b. 1849 · London, New York, T. Audel & co · leaf 310
tch on C. The drive in this case is direct, goingfrom P directly out through T, the gears C and I being locked!~»v the clutch. TRANSATISSIONS 283 Ques. For reverse? Ans. A fifth gear G is used for this purpose; to reverseR, G and L are placed in mesh. The drive then is throughthe gears C, C, R\ G,… … Fig. 169.—Diagram of a three speed selective transmission. With thissystem any of the several speed changes may be made at will without passingthrough the intermediate speeds as is necessary with a progressive transmission. squared shaft for carrying the gears H and F. Gear G is an idlerused for…
Automobiles
