Elementary lessons in steam machinery and the marine steam engine, with a short description of the construction of a battleship (1893)

Langmaid, Joseph, Gaisford, H · London, New York : Macmillan · leaf 123

An illustration from Elementary lessons in steam machinery and the marine steam engine, with a short description of the construction of a battleship, 1893, leaf 123 — along the shaftso that the plates R press against the plates S, the frictionbetween them will cause the clutch box and shaft C to revolvewith A. If it be necessary to stop C, this may be done byseparating the plates B and S by moving the clutch box. Agreat advantage of this appliance is that… … Sectional Elevation.

Steam-engines · Marine engines
