Audels answers on automobiles, for owners, operators, repairmen ... including chapters on the storage battery, electric vehicles, motor cycles, overhauling the car, etc. Fully illustrated and indexed (1911)
Booth, Charles Edwin, b. 1849 · London, New York, T. Audel & co · leaf 322
Fig. 182.—Sectional diagram of bevel gears for a shaft drive, showingarrangement of the propeller shaft and location of the thrust bearings. Fig. 183.—Arrangement of bevel gear for shaft drive; A and B, sleeve andcase for axles and gears; D, the driven gear; E, driving pinion; G, ball bear-ings on…
Automobiles
