Automobile driving self-taught; an exhaustive treatise on the operation, management and care of motor cars (1912)

Russell, Thomas Herbert, 1862-1947 · Chicago, Charles C. Thompson co. · leaf 175

An illustration from Automobile driving self-taught; an exhaustive treatise on the operation, management and care of motor cars, 1912, leaf 175 — spring-pushed con-tact piece G pressed forward by the spring Gi. This is insu-lated from the cover, but is in metallic contact with the ter-minal inside Y2. When the cover is in position, G pressesup against the contact piece Pi (Fig. 29), in the rotating armP, and thus the high tension current is… … PIG. 31—THE COVER OF THE HIGHTENSION DISTRIBUTER. ite disk Q, makes contact with each of these four insulatedsegments in turn. These segments are internally connectedup to terminals Y, Y, Y, Y on the top of the plate S, andfrom these terminals wires run to the different sparking plugs.It will be…

Automobiles

Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
