Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 135

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 135
463J. GASOLINE ATOMIZER.—By injection through the valveaeat K which has a grooved pas-sage around it to distribute the gas-oline evenly to the indraft of thepiston A, the regulating needlevalve. Section ON A-GL … MOTIVB POWER. 129
