ade, and varies so slightly that the differencecan scarcely be illustrated, from the grade over which thedistance travelled is exactly ten times the rise of the road,making the needed pull just ten times smaller than theweight hauled. The discrepancy grows progressively asthe grade gets steeper but… … Fig. 1—Graph of resistances to vehicle movementsdue to grades and irregular or soft road surface.;Each square represents a total resistance deteimined by its vertical and horizontal distance fromlIn zero point at the lower left corner. Thelight area at this corner therefore represents good roads…
