Automotive industries (1899)

Philadelphia [etc.] Chilton [etc.] · leaf 1276

An illustration from Automotive industries, 1899, leaf 1276 — rect. Reverse, 4.27. Rear axle reduction, 4.44 to 1. Iniversal joint. Mechanic. Rear axle, semi-floating.Propulsion, through springs.Torque, through torque arm.Final drive, spiral bevel.Front spring, quarter elliptic.Rear spring, quarter ellipticFoot brake, external on rear wheels.Hand brake,… … 1262 CHEVROLET COPPER-COOLED CAR Automotive IndustriesDecember 28, 19-22

Automobiles · Aeronautics

Internet Archive · University of Toronto Libraries · Public Domain Mark 1.0. Free to use for anything.
