Locomotive text for engineers and firemen; a complete treatise on the engine, electric head-light and standard code of train rules (1908)
National correspondence school of railroading, Chicago. [from old catalog] · [Chicago] · leaf 49
m Valve 33- Stop Ring 16. Water-Valve 34- Coupling Nut i7- Water-Valve Bonnet 35- Tailpiece f36- Steam Spindle 37- Yoke 38. Yoke Gland Interchangeable Parts of 39- Yoke Packing Nut the Screw Motion In- < 40. Yoke Lock-Nut jector: 41. Steam Valve Handle 42. Steam Valve RubberHandle .43-… … PLATE 1.NATHAN 88 MONITOR INJECTOR LOCOMOTIVE INJECTORS. 39 20 and intermediate nozzle 22; thence by heater cockcheck-valve 26, through the spills D to overflow noz-zle 25, thus creating a vacuum in the body of the in-jector, and over the water in feed pipe, causing thewater to be forced to the…
Locomotives
