Aviation engines; design--construction--operation and repair; (1919)
Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley publishing co. · leaf 242
le motor with theconventional cylinder placing, the center line of bothcrank-shaft and cylinder coinciding. The view at B shows Advantages of Offset Cylinders 243 the cylinder placed to one side of center so that its centerline is distinct from that of the crank-shaft and at somedistance from it.…
Airplanes
