Hetzel, Frederic Valerius, 1870- · New York, J. Wiley and Sons · leaf 153
FIG. 121.—Screen Chute for Loading anInclined Belt Conveyor. FIG. 122.—End View of Screen ChuteShown in Fig. 121. feeder and deliver them to a 36-inch belt at belt speed. Some of thedischarge from the apron conveyor, including the drip, falls into the sideextension chute and is put on to the belt…
Conveying machinery · Hoisting machinery · Belts and belting
