irect contact withit. 161. Toeing Nails.—The advantage to bederived from toeing anail lies in the fact thatit always draws inthe direction in whichit is driven. If drivenas shown by a, Fig. 185,it will draw A uponB both in a horizontaland in a vertical direc-tion, and will thus in-sure good contact… … BENCH WORK. I03 EXERCISE No. 8. —Splayed Splice. The stock required is ifx if x 16, from Exercise No. 4 ;the necessary lines are shown by Fig. 186. The finished pieceis represented by Fig. 187. Fig.187Scale, 3=1 II
