bemutilated by the bench-stop if they were placedin direct contact withit. i6i. Toeing Nails.—The advantage to bederived from toeing anail lies in the fact thatit always draws inthe direction in whichit is driven. If drivenas shown by ^, Fig. 185,it will draw A uponB both in a horizontaland in a… … BENCH WORK. 103 EXERCISE No. 8. —Splayed Splice. The stock required is ifx ifX 16, from Exercise No. 4 ;the necessary Hnes are shown by Fig. 186. The finished pieceis represented by Fig. 187. irig.187Scale, Z-=l
