Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc (1919)

Fairfield, Howard Parker, 1858-, Kenison, Ervin, Waite, Edward B. (Edward Broughton), 1873-, American Technical Society · Chicago, American technical society · leaf 199

An illustration from Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc, 1919, leaf 199 — Fig. 93. Geometrioal Constructionfor an Epicycloid … Geometrical Constructionfor an Involute The details of the ellipse, parabola, hyperbola, cycloid, andinvolute will be taken up in connection with the plates. The most important application of the cycloidal and involutecurves is in the cutting of all forms of gear teeth. It has been foundthat the…

Mechanical drawing · Blueprinting

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
