Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc (1919)
Fairfield, Howard Parker, 1858-, Kenison, Ervin, Waite, Edward B. (Edward Broughton), 1873-, American Technical Society · Chicago, American technical society · leaf 208
?5 .^1 ic- , … L_ Q^ ^ s s •^ x ^ ■!JJ0 55 ^ 5 < ^ §1 I 129 64 MECHANICAL DRAYvnNG the circumference at L and Q. With the same radius ?.nd centersat L and Q, draw the arcs cutting the circumference at M and N. The pentagon is completed by drawing the chords EL, L M,MN, NQ, and Q E. Problem 16. To inscribe a…
