Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc (1919)
Fairfield, Howard Parker, 1858-, Kenison, Ervin, Waite, Edward B. (Edward Broughton), 1873-, American Technical Society · Chicago, American technical society · leaf 323
and that its new positionmust be in the line Sb3, it is obvious that its vertical projection isthe point b\ the intersection of a horizontal line drawn through bwith tlie line Sb3. The distance 664 may then be used to determinethe distance from S to b, and determines the position of the latterpoint… … /J Fig. 138 E B DC Frustum of Pentagonal Pyramid 168 MECHANICAL DRAWING 103 Planes with Cones or Cylinders. Sections cut by a planefrom a cone have already been defined as conic sections. Thesesections may be any of the following: two straight lines, circle,ellipse, parabola, hyperbola. All except…
Mechanical drawing · Blueprinting
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
