A C.Y., D MP andC MP, cutting A C.V. in F and E. On AB describe squareASMB ; join S C.V., M C.V. and B C.Y.; through PJ and Fdraw parallels to AS, meeting S C.Y, in H and G; throughG, H draw parallels to SM, meeting M C.Y. in K and L.Draw LN from L _L to MB, and ifiiST from E parallel to AB.This… … The plinth differs froma cube only in the rela-tion of its dimensions;the principle employedin drawing them is thesame, but a particularside of the plinth is men-tioned in reference tothe P.P. or G.P. In thecube this is quite un-necessary, as all the sidesare equal.d Example 1.—Draw a.rf plinth…
