Fig. loi. First Floor Plan. This sketch is now a complete plan of the cellar,and one that can be worked to. It will now be in order to draw the first floorplan, as shown in Fig. loi. Proceed the sameas before, only in this case the outer walls aremade yi inch thick, which represents one foot,making… … Fig. I02. Attic Plan. window openings which are represented by threelines running through the openings {^/i inchwide), which is three feet. The two door open-
