Builder's architectural drawing self-taught : containing descriptions of drawing instruments and accessories, with rules for using them, and hints as to their care and management ... (1903)
Hodgson, Fred. T. (Frederick Thomas), 1836-1919 · Chicago : F.J. Drake & Co. · leaf 66
ach tool or instrument. In selecting triangles it is essential to havethem of a material that will not change shapewith each atmospheric disturbance. For anumber of reasons hard rubber is the best that 48 ARCHITECTURAL DRAWING SELF TAUGHT PLATE 3. On this Plate I show the side frame of the…
Architectural drawing
