Builders' architectural drawing self-taught : containing descriptions of drawing instruments and accessories, with rules for using them, and hints as to their care and management ... (1917)
Hodgson, Fred. T. (Frederick Thomas), 1836-1919, Frederick J. Drake & Co · Chicago, F. J. Drake · leaf 171
ediately requireto know, and after a thorough mastery of theseexamples he will have no difficulty in obtaininga higher knowledge from the thousand and oneother sources that are available, should lie sodesire. SOME MISCELLANEOUS PRACTICE Suppose it is necessary to show a door andcasings in abrick… … Fig. 149. style of door, and finish, and work to scaleaccordingly. In this case I show an elevation,Fig. 151, and plan respectively with a four paneled door withp.. J jamb and soffit lining.Fig. 150 shows a por-tion of the plan en-larged. In this case it willbe seen that the dooris hung to the…
Architectural drawing · Architecture, Domestic
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
