ibe the lines as shown, and finish thesection. A section of a column having flat flutes andfillet is shown at 237. To describe this draw thesemicircle a d c, and divide the quadrant badinto six equal parts, divide a e into five equal 222 ARCHITECTURAL DRAWING SELF TAUGHT parts. With two of these… … one; the width four, and the width of the fillets,one. In Fig. 238 we give a method of describingthe cabled moulding with fillets between. Dividethe semicircle a c d in the same proportion as inFig. 234, giving an equal number as in thatexample. From b, with b e on the compass,describe the…
