Builders' architectural drawing self-taught : containing descriptions of drawing instruments and accessories, with rules for using them, and hints as to their care and management ... (1917)
Hodgson, Fred. T. (Frederick Thomas), 1836-1919, Frederick J. Drake & Co · Chicago, F. J. Drake · leaf 90
off the width AB. On the larger diameter lay off a space equal … Igli ARCHITECTURAL DRAWING SELF TAUGHT PLATE 5. This elevation shows the front and side eleva-tion of the cottage in finished order. Two stylesof drawing are shown, the one being in plain lineand the other shaded. I would not advise thestudent to attempt shading until such time as hefeels assured…
Architectural drawing · Architecture, Domestic
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
