An illustration from The builder's practical director; or, Buildings for all classes, containing plans, sections and elevations for the erection of cottages, villas, farm buildings, dispensaries, public schools, &c., with detailed estimates, quantities, prices, &c. .., 1855, leaf 393
shings of other trades. R () (I V S. The roofs to be framed and puttogethc-r in the manner indicated on thedrawings, with all necessary tilting fillets,valley-pieces etc. Mouldetl wood blocks arcto be fixed at the distances ajiart indicatedon tlie cicvations and in the margin. Therafters to roof…
