Building construction and superintendence, by F.E. Kidder ... (1896)
Kidder, Frank E. (Frank Eugene), 1859-1905 · New York, W.T. Comstock · leaf 288
ches long, the tilebeing laid so as to break joint longitudinally of the arch. Nearly allmanufacturers of hollow tiling make one or more shapes for seg-mental arches, and also different styles of skewbacks to use with them.Hollow tiles for segmental arches are also made both of dense andporous… … jCALt of reet AfiDincneA J£OA\ETRIC VIEW Fig. 183. With this type of arch it is better to use a very heavy or solidskewback without the flange projection, as the thrust on the skew-back is very great where the arch is of wide span. The bottom flangeof the beam should be covered with heavy,…
