Kidder, Frank E. (Frank Eugene), 1859-1905 · New York, Comstock · leaf 498
nning ofbranches to center outlets. Wherever the nailing strips cross the floor beams or girders theyshould be fastened to them by means of iron clamps, made so thatone end can be hooked over the flange of the steel beam and theother end driven into the sirle of the wood strip. When the stripsrun… … JCALS. or rccT ADDincneA lao/AETRic \/inw Fig. 310. Column Covering and Floor Construction, Fair Building, Chicago. hold them with sufficient firmness. The hoop-iron strips shouldbe i^ by ^ of an inch in section and 10 inches long, and shouldbe secured by two clout nails. The concrete used for the…
