l be vertical. GRAPHIC STATICS. 251 If the beam is supported at the bottom only and abuts against acorresponding beam at the top, as in the case of the rafters at the top,then the entire reaction at the top will be horizontal, and at thebottom there must be both a horizontal and vertical reaction,… … 100 .Stress Diagram Fig. If, instead of a suspended load, the load is supported by twostruts, notched into a beam at the bottom, as in Fig. 273, the stressesin the struts and beam are found in precisely the same way as in Fig.271, but in this case it will be found that the arrow heads on a andb…
