Chicago : Engineering and Contracting Pub. Co. · leaf 93
ontg Plan Fig. 1—Plan, Profile and Section of Earth Fill Dam, WillowRiver Land & Irrigation Co. connected up with two 1-in. pipes, leading tothe sump in the gate chamber and providedwith nipples for attaching meters or gages inorder that the seepage and pressure might beascertained at any time… … -r7r-? Section ed Fig. 2—Details of Outlet Tunnel and Approaches. taper pipes of the Venturi Meter type, andoperated by indicator stands at the top ofthe dam, through a concrete tower of hexag-onal shape, 10 ft. in diameter, of concrete 18ins. thick, reinforced with 1-in. round steel, 6ft. long. As…
Buildings
