h the floor to theoutside of the tank, where it discharges into a galvanized-iron goose-neck or delivery-spout. Thedischarge-pipe at the bottom of the tank near the centre of the floor is closed by an ordinary lid-valveoperated by levers and a rope over pulleys from the outside of the tank. The… … Fig. 261.—Cross-section. 124 BUILDINGS AND STRUCTURES OF AMERICAN RAILROADS. Standaid, 16 ft. X 24//., Circular Water-tank, Atchison, Topeka &= Santa Fe Railroad.—Thestandard, 16 ft. X 24 ft., circular water-tank of the Atchison, Topeka & Santa Pe Railroad is 15 ft.6 in. deep in the clear,…
