Gas-engines and producer-gas plants; a practice treatise setting forth the principles of gas-engines and producer design, the selection and installation of an engine, conditions of perfect operation, producer-gas engines and their possibilities, the care of gas-engines and producer-gas plants, with a chapter on volatile hydrocarbon and oil engines (1905)
Mathot, Rodolphe Edgard, 1866- · New York N.W. Henley Pub. Co · leaf 103
Fig. 61.—Correct arrangement of tanks and piping. smoothly at its ma.ximum load for several hours con-secutively. Under these conditions, the reservoir 104 GAS-ENGINES AND PRODUCERS should have a capacity of 45 to 55 gallons per horse-power for engines with hit-and-miss admission, and55 to 65… … FiG. 62.—Incorrect arrangement of tanks and piping. ing a capacity of more than 330 to 440 gallons, theusual diameter being about 3 feet. If the power of the engine be such that severalreservoirs are necessary, then the reservoirs should beconnected in such a manner that the top of the…
