consists of2-in. oak plank on 4-in. X 6-in. mud-sills, spaced 3 ft. ajiart, and well bedded in cinder or ballast.The top of floor is level with the to]) of rails. A 2-ft. smoke-tlue of No. 16 galvanized iron in eachstall takes the smoke from the smoke-stacks of the engines. ENGINE-HO USES. 9o… … Fig. 333.—Cross-section.
