Buildings and structures of American railroads. A reference book for railroad managers, superintendents, master mechanics, engineers, architects, and students (1893)
Berg, Walter G. (Walter Gilman), 1858-1908 · New York, J. Wiley & Sons · leaf 313
, 7 ft. X 8 ft.; two bedrooms, each 9 ft.X 12 ft.; a living-room, 12 ft. X 14 ft.; and a kitchen, 9 ft. X 12 ft. The building has a 12-ft. low 274 BUILDINGS AND STRUCTURES OF AMERICAN RAILROADS. platform along tlie front facing the track, a 12-ft. |>latform at the end of the building next to… … Fig. 503.—Cross-section. Fig. 504.—Gkound-plan. a rise of 2\ in. The building is built without a frame, consisting of two layers of boards nailed to thesills and plates. The foundations consist of posts set in the ground on blocking. The principaltimbers used consist of 6-in. X lo-in. sills; 2-in.…
Railroads -- Buildings and structures · Buildings
