Buildings and structures of American railroads. A reference book for railroad managers, superintendents, master mechanics, engineers, architects, and students (1893)
Berg, Walter Gilman, 1858-1908 · New York Wiley · leaf 270
d withgravel roofing. The principal timbers used are: posts, 12 in. X 12 in.; plates, 6 in. X 12 in.; corbels,6 in. X II in.; knee-braces, 6 in. X 8 in.; bottom chords of roof-trusses, 2 pieces, 3^ in. X 14 in.; prin-cipal rafters, 2 pieces, 3J in. X 12 in.; web-members, 2 in. X 13 in.; purlins, 3… … TopofBuXhiadiM.L.T Si..— ;- Fig. 39S.—Elevaiion on West Strrf.t. tion and plans are published of the new terminal of the West Shore Railroad at the foot of FranklinStreet, on North River, \ew York Citv. An important element of the terminal is the freight-shed 234 BUILDINGS AND STRVCTURES OF…
Building · Railroads
