Buildings and structures of American railroads. A reference book for railroad managers, superintendents, master mechanics, engineers, architects, and students (1893)
Berg, Walter Gilman, 1858-1908 · New York Wiley · leaf 58
Fig. 64.—Front Ei.ev.vtion. Fig. 65. -Cross-section. Fig 66 - Ground PLAN. The ground-floor has two rooms, each 15 ft. X 15 ft., and a kitchen, 12 ft. X 12 ft. The up])erstory is reached by steps leading up from the kitchen at the rear of the house. Design for a Seefioii House In- IK B. Parsons,… … / 1 ^ 7II-.SIQ- S//fi/7^room //-Im/6 \ 1 3-/o;ii- Fig. 67.—Front Elevation. Fig. 68.—Ground-plan. is a two-story frame building with a kitchen annex. On the ground-floor there are two bedrooms, alarge sitting-room, and a kitchen. The second floor can be divided by partitions, or left as one…
Building · Railroads
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
