means of the dotted lines drawn perpendicularly up-wards from the sauie i)oints in the j^lan. Observe … that the full length of the roof is shown hy the lineab in the plan ; but, in the elevation, ab shows itforeshortened, as it appears seen at an angle of 45^.Thus the foreshortened lines in the elevation can beobtained from the full line in the plan. BLACKBOARD LESSONS. 95 But observe that neither…
