level moulding, draw the hor-izontal lines 1, 2, 3, &c. Draw the line fsquare from the rake: set the same distancesfrom this line that you find on the levelmoulding 1, 2, 3, &c. Trace the curvethrough these points 1, 2, 3, &c., and youhave the form of the raking moulding. Hold the… … F?g. 21. Let Fig. 2 i be the square; find the centrea J set the compasses from the corner J, toa ; describe the circle cutting the outside lineat c and 6?; repeat the same at each corner,and draw lines c f h and ij. Theselines will form the octagon desired 25, To draw a hexagon or six-sided Jtg-nre…
