The carpenter's new guide: being a complete book of lines for carpentry and joinery (1848)
Nicholson, Peter, 1765-1844. [from old catalog], Johnston, William, architect. [from old catalog] · Philadelphia, Grigg, Elliot and co. · leaf 158
erable advantage. Fig. B is a roof of this kind, which shows the ends of the purlines, and C shows howto truss the purline. D, E and F are the methods of scarfing timber. 68 DESIGNS OF ROOFS. PLATE 43. Fig. A. A design of a roof to finish with the parapet, when covered in the extentfrom 30 to 40… … I design for a Fiutifioit
Carpentry
