CAL CARPENTRY 119 Fig. 142 is the joint between king-post and prin-cipal rafters at the apex supporting the ridge, apair of 2i by |-inch wrought iron straps, boltedfrom side to side, completing the joint; or, inpractice, a through-bolt from A to B will answerthe same purpose though not so good.… … FIG. 143 Fig. 143 is a queen-post truss for a thirty-twofeet span. The same form is suitable up to aboutforty-two feet span, and beyond that size prin-cesses or intermediate posts and struts have tobe inserted between the queens and the heels ofthe roof, as shown by the dotted lines; and it…
