U j* £ k LU 20 OLD COTTAGES AND FARM-HOUSES the better-class houses are the same, carried out in a rougherand more homely manner. Fig. 17 shows the roof construction at Great Tangley ; Fig. 18that at the guest house, Lingfield ; Fig. 19 a truss to the house at … Hurl Jkoun aJC fi FIG. 19. Godstone shown on Plate xliii. In these a collar beam constructionis observed, the collars supported by a purlin which is strutted upfrom the summer beams holding the wall plates. The gable atBletchingly illustrates the same kind of construction, exposedto view on the…
