Carpentry made easy, or, The science and art of framing, on a new and improved system : with specific instructions for building balloon frames, barn frames, mill frames, warehouses, church spires, etc., comprising also a system of bridge building, with bills, estimates of cost, and valuable tables ... (1857)

Bell, William E · Philadelphia : Howard Challen · leaf 64

An illustration from Carpentry made easy, or, The science and art of framing, on a new and improved system : with specific instructions for building balloon frames, barn frames, mill frames, warehouses, church spires, etc., comprising also a system of bridge building, with bills, estimates of cost, and valuable tables ..., 1857, leaf 64
nd see if they arelevel or parallel with each other. If not, make them so, by cuttingoff the spots under the squares till they become so; then make theother work side square with this one, at these two spots, and draw apencil mark square across both sides: these marks are calledplumb spots. On the… … BALLOON FIJAMIXG. 51 sills, and square the ends by it. If the stick is very irregular, it shouldbe counter-hewed, and the two work sides made square and straight. Spacing for Windows and Boors. Next, lay out spaces for windows and doors, leaving a space for thedoorway 2| or 3 inches more than the…

Carpentry · Bridges
