Foster, Edwin W. [from old catalog] · Garden City, N.Y., Doubleday, Page & company · leaf 282
Tr.th ,t,nt Fig.154. Joints used in construction CONSTRUCTION … Fig. 154. Joints used in construction (continued) No. 8. Shows the lap Joint used for splicing twopieces lengthwise. It needs to be nailed or boltedto prevent pulling apart. No. 9. A middle lap Joint. No. 10. Dovetail lap or lap dovetail. Thisform resists pulling apart and is a combinationof lap…
Carpentry · Woodwork
