Wilson’s Carpentry and joinery / by John Wilson (1891)
Wilson, John · Manchester [England] : Percy Bros. · leaf 92
loped edge. No bottoms are shown, these not being necessary to find the bevels. The sides developed are not lettered, as this part will be understood. It will be seen on looking at the plan of any of the boxes, that the length ofeach piece, both edge and ride it shown; hence when a correct plan is… … WINDOW LININGS— continued. Fig. 1. Represents half front elevation and part isplayed jamb linings, with a segmental head, the cylinder level at the crown. When the linings are narrow the head may be cut out of a solid piece,but as a rule they are thin, bent to the necessary curve upon a…
Carpentry · Joinery
