Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 149
Fig. 488.— Part Sectional Elevation on Line D D (Fig. 489) of Queen-post Truss with Hipped End. … Fig. 489.—Part Plan of Queen-post Truss with Hipped End, showing Timbers—A, Main Truss,B, Half Truss, both being connected at C. TIMBER ROOFS. 131 to the main truss is shown by the partelevation and plan (Figs. 492 and 493); theconstruction will be more clearly understood
Carpentry · Joinery
