Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 157
4X2 Fig. 518.—Detail of Junction at Lower andUpper Rafters. their centres on the partition wall below, thusacting as ties to the back and front walls. Aplate which receives the lower ends ofthe rafters is fixed to the top edges of thejoists. The top ends of these rafters are … rig. 519.—Weak Method of Construction at Headof Queen-post in Mansard Roof. fixed to a plate, upon which the ends of theupper rafters and the ends of the ceilingjoists are fixed, the latter tying in theplates and thus preventing any forcing-outaction of the rafters. The heads of thestuds are also…
Carpentry · Joinery
