Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 173
I 152 CARPENTRY AND JOINERY. … Fig. 585.—Section through Roof Trussed forLead Flat. Fig. 586.—Detail of Junction at A (Fig. 585). Fig. 587.—Section through B B (Fig. 586). Fig. 588.—Detail of Foot of Principal Rafter atC (Fig. 585).
Carpentry · Joinery
