Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 189
at 4 (Fig. 636) is for the backing of the hip— 168 CARPENTRY AND JOINERY. that is, planing the upper edge into twosurfaces, so that each is in the same planeas the adjacent top edges of the rafters ; thiswill be clearly understood by referring toFig. 637. The object of the backing is to is the… … Fig. 640.—Bevel appliedto Hip.
Carpentry · Joinery
