Fig. 35.—Hinge used as Bench Stop. bench, is still largely used. This is thebest form of stop for all ordinary purposes.It is cut wedge shape, as shown by Fig. 32.This stop is raised and lowered by knocking … Fig. 36.—IronBench Stop. Fig. 38.—Morrills Adjust-able Bench Stop. Fig. 37.—Adjustable Iron Bench Stop. with a hammer at top or bottom. Theplane is not injured if it comes into con-tact with the stop, which also has greaterstrength than temporary stops screwedto the face of the bench top. An…
