Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 298
-Detail of Foot ot King-post,(Fig. 891). … Fig. 896.—Detail of Joints at E (Fig. 891). principal, and also the means of supportand bracing. It should be noted that toavoid confusion in this view the bracingconnecting the principals is not shown. Theleading dimensions are figured on the draw-ings, which clearly show the construction,and…
Carpentry · Joinery
