Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 451
* Fig. 1373. |.cs^=c==^ Fig. 1374. Figs. 1373 to 1375.—Part Plan, Elevation, and Section of Pulley Stile, showing Improved Method of Cutting Pocket in Sash Frame. bottom of the opening, etc., are dealt withdifferently. The top cut is the same, but … Fig. 1376.— General View of Cramps and Sash Cramped Up. WINDOW SASHES AND CASEMENTS. 421 less acute, and, instead of a bevelled sawcut at the bottom, two transverse cuts a a(Figs. 1373 and 1374) are made, one at theback and one at the front, J in. apart. Whenthe piece is knocked out, this splits…
Carpentry · Joinery
