Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 550
iled as indicated. Figs. 1677 and1678 show the method of fixing the astragalmoulding, curved facia, and top cornicemoulding. A wall-ground f, which hasbeen rebated on the top edge and splayed SKIRTINGS, DADOS, PANELWORK, LININGS, ETC. 515 on the bottom, is fixed as shown. Tothis the astragal… … Fig. 1673 a vertical section taken throughthe centre, to indicate the method ofbuilding up and fixing. Fig. 1679 shows ahorizontal section through the bottom panelof the pilaster; Fig. 1680, a horizontalsection taken through the pilasters andupper panelling. These views show insection how the…
Carpentry · Joinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
