Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 577
and the joints glued be-fore being placed between the stiles andrails. The framed mouldings are firmlysecured to the stiles and rails by meansof dowels, as indicated at Fig. 1746, andthe holes for these are represented inthe stiles and rails at Figs. 1736 to 1743. The mouldings round the glazed… … Fig. 1749.—Vertical Section through HorizontalCornice, Centre of Pediment, and Fanlight. treated almost in the same manner as acase of solid moulded work, but probablythe former would be found in the end themost satisfactory manner. At Figs. 1740to 1743 are shown the joints between thestiles and…
Carpentry · Joinery
