Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 590
o the vertical trace, giving point e.With h as centre, and e as radius, draw thearc er e. Projecting down and horizontallyfrom e gives point e. Joining this to hgives the bevel required for the application BEVELS: FINDING AND SETTING OUT. 553 to the edge for mitering the stuff. It isnow obvious… … reference to Fig. 1791, which shows pictori-ally the principle of working, the constructionwill be plainly evident. Bevels for Mitered Angles of TriangularHopper.—At Fig. 1792 are shown the plan andelevation of a triangular hopper. Let it berequired to find the angle between the twosurfaces, and…
Carpentry · Joinery
